HICCTV-D thermal imaging monitoring camera

We focus on the innovation and research and development of small and compact infrared thermal imaging cores and have the industrial mass production technology, domestic hardware & software technical engineers who are proficient in optical design, image algorithm, information processing, precision machinery and thermal imaging core technology.

Product Introduction This thermal imaging monitoring camera is used for detecting objects whose temperature is different from the ambient temperature. The camera is equipped with an advanced uncooled thermal imaging detector and can be used independently or as a part of various monitoring systems.. Product Features > Support temperature anomaly detection > High sensitivity 640x480/640x512/384x288 detectors > IP67 protection level

Classification:

Finished thermal imagers

Key words:

HICCTV-D thermal imaging monitoring camera

Message Return

Product Details

CCTV-D IP-online thermal imaging monitoring camera
thermal camera	detector type	uncooled FPA
	resolution	384X288 17um /640X480 17um/ 640x512 12um
	spectral range	8-14um
	Lens	Optional :50mm, 60mm, 75mm
	imaging mirror	support
	contrast/brightness	auto/manual
	Palette	white/black/color
Network	Network Interface	RJ45 standard 10/100M adaptive Ethernet
	stream	main stream:720x576(PAL) / 640x480(NTSC) Secondary stream:320x240
	frame rate	24 fps
	Video compression	H.264/H.265
	Internet protocol	TCP/IP、UDP、RTP/RTCP、RTSP、HTTP、DNS、DDNS、DHCP、FTP、NTP、PPPOE、UPNP、RTMP
	dual stream	support
	safety	Password protection, multi-user access control
other parameters	power	DC12V
	work tempreture	:-40℃-60℃
	storage tempreture	:-45℃-65℃
	power consumption	2W（384）/2.5W（640）
	humidity	<90%
	size	300x110x100mm (with standard lens)
	protection class	IP67
	communication protocol	TTL
